量表
用于內孔的測量。
延伸桿用于深孔的測量。
| 貨號 | 測量范圍 | 分辨力 | 測量深度 | 測頭數量 | 量表（選配） |
|---|---|---|---|---|---|
| 512-01-200 | 18-35mm | 150mm | 9 | 用戶自配量表 | |
| 512-02-200 | 35-60mm | 150mm | 6 | ||
| 512-03-200 | 50-100mm | 150mm | 11 | ||
| 512-04-200 | 50-160mm | 150mm | 12+50mm接桿 | ||
| 512-05-200 | 100-160mm | 150mm | 12 | ||
| 512-06-200 | 160-250mm | 250mm | 5+50mm接桿 | ||
| 512-07-200 | 250-450mm | 250mm | 5+50mm接桿+100mm接桿 | ||
| 512-01-220 | 18-35mm | 0.01mm | 125mm | 7 | 機械百分表 |
| 512-02-220 | 35-50mm | 0.01mm | 150mm | 3 | |
| 512-03-220 | 50-100mm | 0.01mm | 150mm | 5 | |
| 512-04-220 | 50-160mm | 0.01mm | 150mm | 5+60mm接桿 | |
| 512-05-220 | 100-160mm | 0.01mm | 200mm | 4+80mm接桿 | |
| 512-06-220 | 160-250mm | 0.01mm | 250mm | 5 | |
| 512-07-220 | 250-450mm | 0.01mm | 250mm | 5+100mm接桿 |
